WATSON METAL MASTERS' State-of-the-Art Engineering department can provide you with detailed Auto-Cad Mechanical 2020 drawings for review and approval prior to beginning the manufacturing process. Virtually all engineering design functions such as ASME internal and external pressure calculations as well as structural analysis, agitation design and heat transfer surface requirements are performed on custom software applied specifically to tanks and vessels.
AutoCAD drawings can be e-mailed or mailed overnight for quick approval. Many AutoCAD custom programs have been written to speed the design process and improve accuracy and efficiency. All WATSON METAL MASTERS, INC. equipment is designed by highly experienced personnel to strict standards and codes such as ASME, API, UL, AISC, and ASCE. PE stamping is also available.
Complete calculation packages are available when required.
